The weight of a 24-core ADSS optical cable typically ranges from 0.8 to 1.2 kg per meter, depending on design and sheath type.

Cable Construction and Factors Affecting Weight

A 24-core ADSS cable is an All-Dielectric Self-Supporting fiber optic cable designed for aerial installation without metallic support or messenger wires . Its construction includes:

• Loose tube fibers filled with water-blocking gel or compound.
• Aramid yarn layers for tensile strength and reinforcement.
• Polyethylene (PE) or electric tracking resistant (AT) outer sheath.
• Optional double jacket for long-span applications . The weight per meter depends on:
• Number of fibers (24 cores in this case).
• Type and thickness of the outer sheath (single vs. double jacket).
• Amount of aramid reinforcement and water-blocking material.
• Cable diameter, which typically ranges from 10 mm to 14 mm for 24-core ADSS cables .

Typical Weight Range

Based on industry standards and similar 24-core ADSS cables:

• Single jacket 24-core ADSS cable: approximately 0.8–1.0 kg/m.
• Double jacket or heavy-duty 24-core ADSS cable: approximately 1.0–1.2 kg/m . For example, a stranded loose-tube 24-core ADSS cable with a PE sheath and aramid reinforcement designed for spans up to 1000 meters would fall within this range .

Additional Considerations

• Tensile strength: ADSS cables are engineered to support their own weight over spans up to 1000 meters without sagging .
• Environmental suitability: Designed for outdoor use, resistant to ice, wind, and UV exposure .
• Installation: Weight affects tower loading and tension calculations; always consult manufacturer datasheets for precise values before deployment . In summary, while the exact weight can vary by manufacturer and design, a 24-core ADSS cable generally weighs between 0.8 and 1.2 kg per meter, which is sufficient for self-supporting aerial installation over typical transmission line spans.
